Angle Line Machine
-
Brand:Tian Chen
-
ANGLE BAR SIZE:140x140x10~250x250x32 mm
-
MARKING FORCE:1030kN
-
MAX. LENGTH OF RAW MATERIAL:14m
-
CHARACTER SIZE:14x10x19mm
-
NUMBER OF CNC AXIS:3
-
MAX. STROKE OF DRILLING SPINDLE:105 mm
-
MAX. RPM OF THE SPINDLE:560 r/min
-
MOTOR TOTAL POWER:0~40 m/min
-
OVERALL DIMENSION:29000x8900x2500 mm
Description
This angle line machine is the automatic CNC machine for drilling and making angel bars for power transmission tower and tele-communication steel tower. It consists of in-feeding conveyor,transverse conveyor,main machine body,finished angle bar out-feeding conveyor, hydraulic system,pneumatic system and electric control system.
