Description

Main Features:

1. The hydraulic press brake is completely streamlined and meet EU production requirements. The body construction is completed by automated robotic welders and it undergoes a stress relief process with an annealing treatment.

2. The bending brake employs an integrated hydraulic system that is reliable and easy to maintain designed by Bosch-Rexroth in Germany.

3. Work pieces are bent with maximum precision thanks to the sheet metal bending machine's mechanical synchronous mechanism and complex compensatory.

4. The stroke and distance of the metal bender's backgauge is automatically adjusted by the motor and can be adjusted by hand as well. The adjustments are displayed with digital meters.

5. Inch, single, and continuous operation modes are designed for the metal forming machine to be controlled using time relays.

6. A safety barrier and electric inter-locker are designed for the hydraulic press brake to ensure maximum operation safety.

Estun E21s NC Control System for the Hydraulic Press Brake:

1. Monochrome LCD box panel

2. Integral factor freely programmable

3. Automatic positioning control

4. Spindle offset allowance

5. Internal time relay

6. Stock counter

7. Back gauge position display with 0.01mm resolution
